Set line thickness (height)

Easel
1

I have created a line in my drawing but it’s to thick (height), how do I set the thickness (height) of the line.

2

Hi Robert,

In Easel, the line thickness of a line drawn with the line tool is directly related to your bit size.

Here is a GIF Showing that:
Line Thickness

If you are trying to adjust the size of an object, you can select it and either click and drag one of the nodes or adjust the width and height in the Shape window on the right side of the object.

Here is a GIF of that:
Adjusting Size

This YouTube video will talk more about sizing objects in Easel:

You can find a whole set of videos on getting started with Easel here:https://www.youtube.com/playlist?list=PLAmM1KFD0JzbWUqcG_cDzYNDBxjVg7TjS

All the best,
